Description
- Hydraulic synchronization, hydraulic lock and mechanical double safety device, automatically unlocking when lowered
- 24V safety control circuit
- The oil cylinder parts are processed by high-speed fully automatic CNC lathes. It ensures excellent concentricity and smoothness, and the cylinder barrel is rolled and mirrored
- Adjustable platform length
- Shot blasting surface treatment, high-temperature spray treatment, and durability guaranteed
- All shaft positions are equipped with wear-resistant bearings
Products Parameters
| Rated lifting weight | 4000kg | Power | 3kw |
| Initial height | 330mm | Power supply | 220V/380V |
| Lifting height | 1999mm | Drive mode | Electro-hydraulic |
| Platform length | 1560-1760mm | Hydraulic oil | 46# Anti-wear hydraulic oil 16 L |
| Platform width | 565mm | Air pressure | 6~8bar |
| Net weight of the whole machine | 761kg | Working temperature | 5~40°C |
Maintenance tips
- Overloading work is prohibited. When the lifting sound is abnormal or cannot be started, it should stop working, find out the reason, and eliminate the fault before continuing to use it.
- Regularly add grease to the parts that need to be greased.
